SPECIFICATIONS
PERFORMANCE
225 lb Weight Stack
5 lb Increment Weight
30 lb Top Plate (2 x 15 lb Plates)
13 x 15 lb Plates
Pulley Ratio: 0.7 x Ext Weight, 0.5 x Curl Weight
FRAME
LOOS USA Cables
Heavy Gauge Steel Frame
Low Profile Design
High-Quality Electrostatic Powder Coat Finish
Fully Enclosed Weight Stack
Steel Feet with Rubber Foot Covers
CONVENIENCE
Rep/Time Counter (2 C Batteries required, not included)
Start/Finish Workout Diagrams
Storage Trays (Top of Weight Tower)
Easy-Adjust Seat Back
DIMENSIONS
Set-Up Dimension: 55.4″ L x 54″ W x 62.2″ H
Assembled Unit Weight: 625.2 lb
Recommended User Height: 4€™11€ to 6€™8€
Max User Weight Capacity: 360 lb
WARRANTY
US COMMERCIAL WARRANTY
10 Years Frame
5 Years Bushings, Bearings, Shocks, Pulleys, Guide Rods
1 Year Paint and Finishes, Cables, Grips, Counter/Timer, Pull-Pin Components, Rail Wheels, Attachments, All Other Parts Not Mentioned
6 Months Upholstery
1 Year Labor
*Prisons and correctional facilities are excluded from warranty coverage.
