The Star Trac 8 Series Upright Bike is engineered for long-lasting performance in high-traffic fitness facilities. Featuring the ultra-durable Morse Taper bottom bracket and pedal system, it delivers the stability and reliability commercial operators depend on day after day.

Ergonomically designed for a smooth, natural ride, the 8UB accommodates all fitness levels with an easy-up ratcheting seat and contact plus telemetric heart-rate monitoring. This configuration ships with the Apex 16″ HD Touch display on the Core Health & Fitness OpenHub ecosystem for interactive HIIT programming, wireless device mirroring, and streaming apps like RunTV.

Key Features

• Apex 16″ HD touchscreen with onboard HIIT20 programming and 20+ workouts
• Wireless device mirroring, casting, and integrated apps including RunTV scenic routes
• Apple GymKit and Samsung Galaxy Watch Tap-to-Pair via NFC
• Ultra-durable Morse Taper bottom bracket and pedal system
• Easy-up ratcheting seat with 13 positions; contact & telemetric heart rate
• Command center: wireless phone charger, cooling fan, USB port, and bottle holders

Specifications

• Console: Apex 16″ HD Touch Display (OpenHub, over-the-air updates)
• Connectivity: Ethernet and WiFi enabled; integrated apps; wireless screen mirroring and casting
• Bottom Bracket: Morse Taper
• Pedals: One-sided self-leveling platform with removable ratcheting strap
• Seat Adjustment: Easy-up ratcheting seat, 13 positions
• Heart Rate: Contact and telemetric
• Drive System: Alternator
• Resistance Levels: 20
• Max User Weight: 350 lbs (159 kg)
• Frame: Powder-coated steel, Matte Black (-60); custom frame colors available
• Assembled Dimensions: 46″ x 25″ x 63″ (117 x 64 x 160 cm)
• Product Weight: 150.8 lbs (68.5 kg)
• Shipping Dimensions: 47.6″ x 26″ x 42.3″ (121 x 66.1 x 107.5 cm)
• Shipping Weight: 172.8 lbs (78.4 kg)
• Power: Touchscreen display requires 12V / 5A power supply
• Model / SKU: 9-8160-8UB-16IN-60

Download the Star Trac 8UB Upright Bike product sheet (PDF)
